We also maintain continuous, high-quality checks to ensure maintaining the consistency of the product.
Rapid Wall PANEL Installation
Renacon wall panel are a safe and sturdy solution for your home. These solid wall panels are made up of two fibre reinforced cement sheets that are neatly placed on either side of a lightweight concrete core to balance its weight with the occupied space. Meticulously designed to occupy less space while being lightweight, these panels are manufactured to be eco-friendly and sustainable.Â
KEY FEATURES
- Light, strong & durable cement-based panelsÂ
- High axial compression & bendingÂ
- Extreme weather resistance
- Reusable
- Energy efficient
- Fire resistantÂ
- Termite resistantÂ
Versatile Application Areas
âž” Accommodation Units
âž” Site Offices
âž” Security & Store Rooms
âž” Warehouses
âž” Godowns
âž” Army Barracks
âž” Schools
âž” Low-cost Housing
PREFAB STRUCTURES
âž” Offices
âž” Malls
âž” Educational Institutions
âž” Hotels
âž” Residential areas
âž” Industrial areas
âž” Government units
âž” Defence Installations
PARTITIONS
âž” Residential
âž” Industrial
âž” Commercial
âž” Government
âž” Defence
BOUNDARY
âž” Shopping Malls
âž” Hotels
âž” Staircase Enclosures
FIRE SEPARATION WALLS
dimensional advantages
SAFETY
- Fire resistant
- Water resistant
- Termite resistant
- Able to withstand extreme weather
STRONG
- Light, strong, durable, cement based panels
- High axial compression & bending
SPACE
- Thinner Walls
- Extra Carpet Area
SAVINGS
- Pre-cured to save on site curing
- Faster installation saves time
- Lesser Labour saves cost
- Lightweight for structural saving
SUSTAINABLE
- Lesser dust during construction
- No water needed
- Reusable
SERVICE
- Support for design & BOQ
- Regular training on product use
- Site visits & feedback
Technical Specifications
| Parameter | Unit | Test Standard/ Condition | Typical Value |
| Length | mm | – | 2400/3000 |
| Width | mm | – | 600 |
| Thickness | mm | – | 50/75 |
| Edge Profile | – | – | Tongue and Groove |
Physical & Mechanical Characteristics
| Parameter | Unit | TestStandard/Condition | 50mm | 75mm |
| Nominal weight | Kg/m2 | Weight | 42 | 47 |
| Axial Compression Strength | Kg/m2 | IS 2380 | 250 | 270 |
| Apparent Density | Kg/m2 | IS 2380 | 831 | 840 |
| Tensile Strength (parallel to the surface) | N/mm2 | IS 2380 | 3.7 | 5.5 |
| Tensile Strength (perpendicular to the surface) | N/mm2 | IS 2380 | 1.7 | 2.8 |
| Core Bonding Strength | N/mm2 | IS 2380 | 1.22 | 1.18 |
| Modulus of rupture | Kg/m2 | IS 2380 | 51 | 60 |
Thermal Characteristics
| Thermal Conductivity | W/mk | ASTM C 177 & ISO 8302 | 0.24 | 0.26 |
Fire Characteristics
| Non – Combustibility | – | BS 476 Part 4 | Non – Combustible |
Environmental Friendly Characteristics
| Termite Resistance | – | IS 4833 | No Termite Attack |
| VOC Organic Emission | – | ISO 16000-6 | Not Detected |
